SANEI ELECTRIC INC.

BL2-58

Features

Small footprint and lightweight (265g approx.）
80mm/sec (max.) printing speed *1
58mm paper width
Drop-in paper loading
Label printing (option)
Label design software available

*1: Use dedicated AC adapter, printing ratio 12.5%
＊Specifications are subject to be changed for improvement without notice.

Request Quote

Downloads

Specifications

Printing method	Direct line thermal
Direct line thermal	384dots
Resolution	8dots/mm (203dpi)
Paper width	58mm
Printing width	48mm
Paper roll diameter	Max φ50mm
Printing speed	Max. 80mm/sec.
Character size , Characters / line	FontA：24x12dots (1.5×3.0mm) , 32 characters/line FontB：16x8dots (1.0×2.0mm) , 48 characters/line
Character type	Alphanumeric,International, PC437/850/852/857/858/863/865/866/WPC1252 Katakana
Interface	Serial(RS-232C) / Parallel (Centronics)/ USB 2.0
Logo registration	Download bitimage
Barcode	UPC-A/E , JAN13/8 , CODE39 , ITF , CODABAR , CODE128
2D barcode（Option）	QRcode , Maxicode , PDF417 , DataMatrix , MicroPDF417
Input buffer	8k bytes
Setting position	Horizontal/Vertical（Wall mount）
Regulations	VCCI B、FCC B、CE marking
Service life	Pulse activation : 100million pulses or more （Room temperature, Printing ratio 12.5％） Abrasion resistance : 50Km or more
Power supply	AC adapter Part No.： BLS-120W Input ： AC100 to 240V, 50 to 60Hz, 1.0A Output ： DC9.0V, 3.0A
Power consumption	Standby： 50mA or less Printing： Ave. 2.6A(Peak 3.7A) *DC7.4V, Printing ratio 25%, at room temperature
Operating condition	Temperature： -10℃ to +50℃（Using battery） Humidity： 20%RH to 85%RH（No condensation） AC adapter : 0℃～+40℃ Guaranteed printing quality : +5℃～+40℃
Storage condition	-20℃-＋60℃/10％RH-90％RH（no condensation）
Dimensions (W×D×H)	93×125×70mm
Weight	265g （ paper not included）
Paper roll	Recommendable paper： TF50KS-E2D（Nippon Paper Industries） Paper width： 57.5mm +0.5mm –0 Thickness： 62µm to 95µm Diameter： φ50mm or less
