Features

  • 12V power supply

    (Suitable for solar battery systems)

  • 150mm/sec. printing speed

  • Energy saving mode

  • Small foot print and light weight

  • Wide operating temparature range

  • Easy paper loading with side open head

  • Made in Japan
*1: Use AC adapter, printing rate less than 25%
* Specifications is subject to be changed for improvement without notice

Specifications

Printing method

Direct line thermal

Paper width

58mm / 60mm

Printing speed

Max.150 mm/s *1
Max.120 mm/s (Save Mode)

Resolution

8 dots/mm (203dpi)

Paper roll diameter

Max. Φ120mm

Paper thickness

59~100um (50g/m2~85g/m2)

Paper core Internal dia

Φ12mm or Φ25.4mm

Print width

54mm / 56mm

Number of dots

432 dots / 448 dots

Interface

Serial(RS-232C), USB

Paper Sensors

Near end sensor, Paper empty sensor, (Shared use) Black mark sensor

Paper Near end

Φ21.0、24.5、35.0mm

Paper loading method

Head open lever, Auto-loading

Cutter

Partial cut / Full cut

Character type

ASCⅡ: PC437/850/852/857/858/863/865/866/860/862/864/737 WPC1252/1252_2/1254/1250/1251 Square form of kana (the Japanese syllabary)

Download: Download

Font / Dots / Lines

Printing width: 54mm / 56mm /

ASCⅡ 16 dots: 8 x 16 dots(WxH) 54/56 lines

ASCⅡ 24 dots: 12 x 24 dots (WxH), 36/37 lines

Jfont 16 dots: 16 x 16 dots(WxH) 27/28 lines

Jfonrt 24 dots: 24 x 24dots(WxH) 18/18 lines

Memory

Input buffer 8k bytes, User memory, Non-volatile memory

Logo registration

Download bit image

Barcode

1D: UPC-A/E, JAN13/8, CODE39, ITF, CODABAR, CODE128

2D (option): QR, Maxicode, MicroPDF417, PDF417, DataMatrix

Command systems

ESC/POS Conformity

*ESC/POS is registered trademark of Seiko Epson Corporation.

Setting position

Horizontal surface

Regulation

VCCI, FCC, CE, CLASS A

Printing life

Pulse activition: 200 million pulses or more
Abrasion resistance: 150Km or more

Cutter life

Cutting life: 1.5 million cuts or more (Thickness: 75µm or less)

Power supply

DC 12.0V±10%

Current consumption

Standby: 100mA or less
Printing: Standard mode:Average 2.5A
Save Mode: Average 1.5A

*DC12.0V, Printing rate 12.5%, at room temperature

Operating environment

Temperature: -20℃ to +50℃

Humidity: 20%RH to 85%RH(No condensation)
At the condition of 34℃ and 85%RH

Storage environment

Temperature: -30 to 70 ℃

Humidity: 10%RH to 90%RH (No condensation)

Dimensions (without protruding parts)

φ83mm : 104×129.2×73.6mm(W×D×H)
φ102mm : 104×137.3×79.5mm(W×D×H)
φ120mm : 104×145.5×85.4mm(W×D×H)

Weight

525g (Without paper roll)

Features

12V power supply

Energy saving mode

Made in Japan

Accessories

  • CB-SK1-D1
